◆Power
AC power:100-240 V AC, 50/60 Hz
Rated power:600W@220V
◆Optics
Lamp:400W LED
Rated life:20000h
LUX:5m 120000 lm
Beam angle:4°~45°
◆Effects
Verticalscanning:Manuallyrotate360 °
Shutter:0~30HZ
Dimming:0-100% coarseandfinecontro
Color:8 colors + white light, half color function Linear CMY+CTO toning system
Fixed pattern :12 fixed patterns + white light
Rotation pattern :7 glass patterns, each glass pattern can be independent positive and negative rotation
Prism system:standard single six row prism and 8 prism, each prism can be independent positive and negative direction
Focus:DMX linear adjustment
Macro function:console reset function, self - walk mode, master - slave mode
◆Control
Control and Programming:DMX512 With RDM function, software can be upgraded online, dial the address code
DMXchannels:22CH/26CH
◆Physical characteristics
Protection rating:IP20
Housing:High temperature resistant flame retardant plastic
Display mode:LCD display, button + touch dual operation mode
Cooling mode:use axial fan to strengthen cooling
AC power in/thru:Neutrik PowerCon
DMX data in/out:3-pin locking XLR
Weight:24kg
Ambient temperature:-20℃~40℃(-4℉~104℉）
Size:380x290x680mm
