◆TECHNICAL SPECIFICATION
Length： 39.4” (1002mm)
Width： 5.12” (130mm)
Height (w/o yoke)：8.27” (210mm)
Weight： 17kg
◆POWER
Operating Voltage：100-277VAC 50/60Hz
Fus：12A 250V slow-blow (5x20mm)
Power consumption：1400W
◆LIGHT SOURCE
LEDs：108*10W RGBW LEDs divided into 12 pixels
Color：RGBW
Beam spread：36°
Intensity control：16bit or 8bit
Refresh rate：From 400 to 24K
◆AVERAGE COLOR WAVELENGTH
Red：625 nm
Green：530 nm
Blue：460 nm
White：>5700K
Refresh rate：1200Hz
◆THERMAL
Max. ambient temperature： +104°F (+40 °C)
Min. ambient temperature：-4 °F (-20 °C)
Cooling：air cooled – fan
◆CONTROL / PROGRAMMING
DMX input：locking 5-pin XLR male socket
DMX output：locking 5-pin XLR female socket
DMX pin config：pin 1 shield, pin 2 (-), pin 3 (+), pin 4 n/a, pin 5 n/a
Control：RDM, DMX-512, ArtNet,sAcn, Manual Mode
DMX Channels：9,19,53
Power Connector： Input: PowerCon 20A
◆IP RATED
IP Rated：IP65
